MPCB

• Application
• Motor Protection and Control

• Color
• White/Grey

• Connection Type
• Screw Terminals

• Connector Type
• Screw Type

• Dimension (L*W*H)
• 90 x 45 x 73 mm

• Efficiency
• Up to 98%

• Energy Consumption
• Low

• Feature
• Trip Indication, Adjustable Current Setting, High Breaking Capacity

• Frequency (MHz)
• 50/60 Hz

• Humidity %
• Up to 95% RH

• IP Rating
• IP20

• Input Voltage
• 690 V AC max

• Insulation Material
• Thermoplastic

• Material
• High-grade Plastic & Metal

• Mounting Type
• DIN Rail Mount

• No Of Poles
• 3

• Operating Temperature
• -20C to +60C

• Output Type
• Manual ON/OFF

• Overheating Protection
• YES

• Phase
• Three Phase

• Power Factor
• High

• Product Type
• Manual Motor Starter

• Protection Level
• Other, Short Circuit & Overload

• Rated Voltage
• 690 V AC

• Shape
• Rectangular

• Size
• Standard

• Surface Finish
• Matte

• Weight
• 0.29 kg

• Poles Number
• 3
