Push Button

• Automation Grade
• Manual

• Circuit Type
• SPST (Single Pole Single Throw)

• Color
• Red, Green, Yellow

• Contact Resistance
• 50m

• Current Rating
• 5A

• Finish Type
• Glossy

• Insulation Resistance
• 100M (at 500V DC)

• Material
• High-Quality Plastic

• Max. Current
• 5A

• Max. Voltage
• 250V AC

• Mechanical Life
• 100,000 cycles

• Mounting Type
• Panel Mount

• No Of Poles
• 1

• Number of Module
• Set of 3

• Operating Temperature
• -10C to +55C

• Product Type
• Push Button Set

• Protection Level
• IP40

• Rated Voltage
• 220V AC

• Response Time
• 20ms

• Size
• Standard Panel Mount (22mm diameter)

• Stoke
• 2.5mm

• Temperature Range
• -10C to +55C

• Weight
• Approx. 20g per piece

• Automation Grade
• Manual

• Circuit Type
• 1 NC (Normally Closed)

• Color
• Red

• Contact Resistance
• <= 25 mOhm

• Current Rating
• 3 A (AC-15), 2 A (DC-13)

• Finish Type
• Glossy

• Insulation Resistance
• >= 10 MOhm at 500 VDC

• Material
• Plastic and Metal

• Max. Current
• 10 A

• Max. Voltage
• 600 V

• Mechanical Life
• 300,000 cycles

• Mounting Type
• Panel Mount

• No Of Poles
• 1

• Number of Module
• Single

• Operating Temperature
• -40C to +70C

• Product Type
• Emergency Stop Mushroom Push Button

• Protection Level
• IP66, IP67, IP69, IP69K, NEMA 13

• Rated Voltage
• 600 V

• Response Time
• Instantaneous

• Size
• 22 mm mounting diameter

• Stoke
• 40 mm head diameter

• Temperature Range
• -40C to +70C

• Weight
• ~50 g

• Automation Grade
• Manual

• Circuit Type
• 1 NC (Normally Closed)

• Color
• Red

• Contact Resistance
• 25 m

• Current Rating
• 3 A at 240 V AC

• Finish Type
• Glossy

• Insulation Resistance
• >10 M at 500 V DC

• Material
• Plastic (Body), Metal (Key)

• Max. Current
• 3 A

• Max. Voltage
• 600 V AC/DC

• Mechanical Life
• 300,000 cycles

• Mounting Type
• Panel Mount

• No Of Poles
• 1

• Number of Module
• Single

• Operating Temperature
• -40C to +70C

• Product Type
• Key Emergency Switching Off Push Button

• Protection Level
• IP66, IP67, IP69, IP69K, IK06

• Rated Voltage
• 600 V

• Response Time
• Instantaneous

• Size
• 22 mm mounting diameter, 40 mm head diameter

• Stoke
• 40 mm mushroom head

• Temperature Range
• -40C to +70C

• Weight
• Approx. 62 g
