Schneider Electric Harmony XB5N Selector Switch 22 mm, Black, 1 NO, 2 Position, Stay Put | XB5AD21N

Name: Schneider Electric Harmony XB5N Selector Switch 22 mm, Black, 1 NO, 2 Position, Stay Put | XB5AD21N
Brand: Leon Enterprise
Price: 310.0 INR
Availability: InStock

Price 310.0 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Schneider Electric Harmony XB5N Selector Switch 22 mm, Black, 1 NO, 2 Position, Stay Put | XB5AD21N Specification

Automation Grade
Industrial

Protection Level
IP66, IP67, IP69, IP69K, Type 4X, 13

Number of Module
Single

Circuit Type
1 NO (Normally Open)

Max. Current
10 A (conventional thermal current)

Finish Type
Matte / Textured

Response Time
< 20 ms (typical mechanical response)

Rated Voltage
230 V (AC/DC)

Temperature Range
Storage: -40C to +70C, Operation: -40C to +70C

Mechanical Life
1,000,000 cycles

Product Type
Selector Switch

Material
Plastic (Operator), Metal (Mounting Collar)

Insulation Resistance
>= 10 megaohms at 500 V DC

Contact Resistance
<= 25 milliOhms at 6V, 1A, per IEC 60947-5-1

Max. Voltage
Ui 500 VAC/DC

Operating Temperature
-40C to +70C

Stoke
Short (stay put)

Size
22 mm mounting diameter

Color
Black

Weight
Approx. 52 g

Mounting Type
Panel Mount, 22 mm cut-out

Current Rating
6 A (AC-15), 2.5 A (DC-13)

No Of Poles
1 Pole

Body Style
Modular

Ambient Air Temperature For Operation
-40...+70 C

Terminal Type
Screw clamp terminals

Command Actuator Type
Knob

Vibration Resistance
5 gn (10...500 Hz) per IEC 60068-2-6

Tightening Torque
0.8 Nm (terminal), 2.2 Nm (mounting collar)

Illumination
Non-illuminated

Shock Resistance
30 gn, 11 ms per IEC 60068-2-27

Switch Action
Stay Put, 2 Position (Maintained)

Front IP Degree
IP66, IP67, IP69K

Contact Operation
Snap action

Ambient Air Temperature For Storage
-40...+70 C

Standards/Certifications
IEC 60947-5-1, UL, CSA, CE, CCC, EAC

Head Type
Standard

About Schneider Electric Harmony XB5N Selector Switch 22 mm, Black, 1 NO, 2 Position, Stay Put | XB5AD21N

Experience kingly reliability with the Schneider Electric Harmony XB5N Selector Switch 22 mm, Black, 1 NO, 2 Position, Stay Put | XB5AD21N. This brilliant panel mount switch garners favorable reviews for its ultimate design, robust construction with plastic operator and metal mounting collar, and top industrial performance. Rated for IP66, IP67, and IP69K protections, the switch supports a wide temperature range (-40C to +70C) and offers a modular body style for easy integration. Certified by IEC, UL, CSA, CE, and more, it's an excellent choice for critical operations. A top sale product for those demanding unrivaled durability and dependable switch action.

Versatile Applications & Superior Features

The Schneider Electric Harmony XB5N Selector Switch is engineered for command and control media across industrial automation systems. With its stay put mechanism, 2-position maintained action, and high shock and vibration resistance, it ensures secure, uninterrupted use. Its modular design and easy screw clamp terminals facilitate rapid installation. Ideal for machinery and control panels, this selector switch excels where reliability and safety are paramount, accommodating diverse automation applications in demanding environments.

Export Markets & Shipping Excellence

Shipped goods featuring the Schneider Electric Harmony XB5N Selector Switch reach international export markets across Europe, Asia, and the Americas. Purchase orders are processed efficiently, ensuring swift transportation and on-time delivery within agreed timelines. Each selector switch is packaged securely to maintain product integrity during transit, catering to distributors and end-users alike. The packaging process and logistics are streamlined, offering customers reliable supply and peace of mind throughout the delivery process.

FAQ's of Schneider Electric Harmony XB5N Selector Switch 22 mm, Black, 1 NO, 2 Position, Stay Put | XB5AD21N:

Q: How is the Schneider Electric Harmony XB5N Selector Switch installed?

A: The switch is designed for easy panel mounting using a 22 mm cut-out and is secured with a screw clamp terminal for quick, reliable connection.

Q: What benefits does the stay put mechanism offer during operation?

A: The stay put feature provides precise position control, ensuring the actuator remains in its selected position even in vibration-prone environments, which enhances operational safety and convenience.

Q: Where can I use the Harmony XB5N Selector Switch?

A: This selector switch is ideal for industrial automation panels, machinery command systems, and equipment requiring high durability and standards compliance, including environments exposed to harsh elements.

Q: What certifications does the XB5AD21N model comply with?

A: It meets IEC 60947-5-1, UL, CSA, CE, CCC, and EAC certifications, ensuring global acceptance and trusted safety compliance.

Q: How long does it typically take for shipped goods to arrive after placing a purchase order?

A: Delivery time varies depending on location and shipping arrangements but is generally prompt, with orders securely packaged and transported to minimize delays.
